The Trimble BD910 GNSS receiver module has been designed for applications requiring high accuracy from multiple GNSS constellations in a very small package. Mobile platforms can now embed proven Trimble RTK technology using a shielded module in a compact 41 mm x 41 mm x 7 mm form factor. The Trimble BD910 is a complete drop-in, solder-down module manufactured and tested to Trimble's highest quality standards. This design ensures the high quality GNSS signals are protected from the sources of EMI on the host platform. It also significantly reduces radiated emissions which speeds compliance certification and time to market.
| Size | 41 mm x 41 mm x 7 mm |
| Power | 3.3 V DC +5%/ - 3% Typical 1.1 W (L1 GPS + L1 GLONASS) |
| Weight | 19 grams |
| Connectors | I/O: 80 pin Narrow Pitch Panasonic Socket GNSS Antenna: MMCX receptacle |
| Antenna LNA Power Input: | Input voltage: 3.3V DC to 5V DC Maximum current: 400 mA Minimum required LNA Gain: 24.5 dB |
- 220 Channels for Multi-Constellation GNSS Support
- Fully EMI Shielded Module
- Advanced Kalman Filter PVT Engine
- Compact Design for Mobile Applications
- Flexible RS232, USB and Ethernet Interfacing
- L1 RTK Centimeter-Level Position Accuracy
- Proven Trimble Maxwell 6 Technology
- Supports FDE and RAIM
Technické údaje
- Přesnost GNSS: 1 cm
- Satelitní systémy: GPS + GLONASS + GALILEO
